Surge Protection Devices (SPDs)
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Form | Number of Poles | Voltage - Continuous Operating (Max) (MCOV) | Current - Discharge (Nom) (8/20µS) | Current - Discharge (Max) (8/20µS) | Operating Temperature | Voltage - Protection Rating (VPR) | Voltage - Protection Level (VP) (2416) | Operating Temperature | Features | Mounting Type | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
BSPM2240S3GSPD TYPE 2 550VAC MCOV 2 POLE |
4,321 |
|
Datasheet |
BSPM | Bulk | Obsolete | Type 2 | Base + Module | 2 | 550VAC | 20 kA | 40 kA | 200 kA | 1.8 kV | - | - | Remote Signaling Contacts, Thermally Protected | DIN Rail | CE, cURus, UL |
|
|
AGDN024SPD TYPE 1 28VDC MCOV 1 POLE |
7,664 |
|
Datasheet |
- | Bulk | Active | Type 1 | Base + Module | 1 | 28VDC | 10 kA | - | - | - | - | -40°C ~ 85°C | Visual Life Indicator | DIN Rail | UL |
|
|
AGDN048SPD TYPE 1 52VDC MCOV 1 POLE |
7,356 |
|
Datasheet |
- | Bulk | Active | Type 1 | Base + Module | 1 | 52VDC | 10 kA | - | - | - | - | -40°C ~ 85°C | Visual Life Indicator | DIN Rail | UL |
|
|
AGDN012SPD TYPE 1 12VDC MCOV 1 POLE |
3,789 |
|
Datasheet |
- | Bulk | Active | Type 1 | Base + Module | 1 | 12VDC | 10 kA | - | - | - | - | -40°C ~ 85°C | Visual Life Indicator | DIN Rail | UL |
|
|
16005.2SPD TYPE 2 280VAC MCOV 4 POLE |
2,878 |
|
Datasheet |
CP VH | Box | Active | Type 2 | Base + Module | 4 | 280VAC | 80 kA | 160 kA | - | 400 V | 1.25 kV | -40°C ~ 85°C | Remote Signaling Contacts | DIN Rail | - |
|
|
SSP030DRSE10SPD 320VAC MCOV 1 POLE |
9,023 |
|
Datasheet |
- | Box | Active | - | Module Only | 1 | 320VAC | - | 10 kA | - | 1 kV | - | - | - | Chassis Mount | - |
|
DLA-06D3-EXSPD 72VDC MCOV 2 POLE |
2,483 |
|
Datasheet |
- | Active | - | Base + Module | 2 | 72VDC | 10 kA | 20 kA | - | - | - | -40°C ~ 85°C | - | DIN Rail | UL | |
|
DLA-48D3-EXSPD 72VDC MCOV 2 POLE |
7,347 |
|
Datasheet |
- | Active | - | Base + Module | 2 | 72VDC | 10 kA | 20 kA | - | - | - | -40°C ~ 85°C | - | DIN Rail | UL | |
|
DLA-24D3-EXSPD 72VDC MCOV 2 POLE |
3,284 |
|
Datasheet |
- | Active | - | Base + Module | 2 | 72VDC | 10 kA | 20 kA | - | - | - | -40°C ~ 85°C | - | DIN Rail | UL | |
|
DLA-12D3-EXSPD 72VDC MCOV 2 POLE |
8,381 |
|
Datasheet |
- | Active | - | Base + Module | 2 | 72VDC | 10 kA | 20 kA | - | - | - | -40°C ~ 85°C | - | DIN Rail | UL | |
|
|
BSPD48RJ45SPD 34VAC/48VDC MCOV 4 POLE |
6,054 |
|
Datasheet |
BSPD | Bulk | Active | - | Module Only | 4 | 34VAC, 48VDC | 2.5 kA | 10 kA | - | - | 600 V | -40°C ~ 80°C | - | DIN Rail | UL |
|
|
AGDN40030RSPD TYPE 1 480VAC MCOV 3 POLE |
3,126 |
|
Datasheet |
- | Bulk | Obsolete | Type 1 | Base + Module | 3 | 480VAC | 20 kA | - | 200 kA | 1.5 kV | - | -40°C ~ 85°C | Visual Life Indicator | DIN Rail | UL |
|
|
AGDN48030RSPD TYPE 1 550VAC MCOV 3 POLE |
3,468 |
|
Datasheet |
- | Bulk | Active | Type 1 | Base + Module | 3 | 550VAC | 20 kA | - | 200 kA | 2 kV | - | -40°C ~ 85°C | Visual Life Indicator | DIN Rail | UL |
|
|
SPD2-750-MSPD TYP 1/TYP 2 750V MCOV 1 POLE |
5,965 |
|
Datasheet |
SPD2 2P+0 | Bulk | Active | Type 1, Type 2 | Module Only | 1 | 750V | 20 kA | 50 kA | 200 kA | 2.5 kV | 3.4 kV | -40°C ~ 80°C | Thermally Protected, Visual Life Indicator | DIN Rail | CE, cURus, UL, VDE |
|
|
SPD2-PV15-3P0SPD TYP 1/TYP 2 1.5KV MCOV 3POLE |
9,422 |
|
Datasheet |
SPD2 PV | Bulk | Active | Type 1, Type 2 | Base + Module | 3 | 1.5kV | 20 kA | 40 kA | 65 kA | 4 kV | 4.8 kV | -40°C ~ 80°C | Thermally Protected, Visual Life Indicator | DIN Rail | CE, cURus, UL, VDE |
|
2025040000SPD TYPE 2 180VAC MCOV 1 POLE |
3,214 |
|
- |
VPU | Box | Obsolete | Type 2 | Base + Module | 1 | 180VAC | 20 kA | 40 kA | 200 kA | 800 V | - | -40°C ~ 70°C | Remote Signaling Contacts | - | cURus |
|
DS72US-230SSPD TYPE 2 320VAC MCOV 4 POLE |
9,803 |
|
- |
- | Active | Type 2 | Base + Module | 4 | 320VAC | 20 kA | 75 kA | 150 kA | 1.8 kV | - | -40°C ~ 85°C | Remote Signaling Contacts | DIN Rail | - | |
|
DS72US-120SSPD TYPE 2 255VAC MCOV 4 POLE |
5,377 |
|
- |
- | Active | Type 2 | Base + Module | 4 | 255VAC | 20 kA | 75 kA | 200 kA | 1.5 kV | - | -40°C ~ 85°C | Remote Signaling Contacts | DIN Rail | - | |
|
|
PXSPDRDCAB08SPD 1 POLE |
3,473 |
|
- |
PXSPD | Bulk | Active | - | Base + Module | 1 | - | - | - | - | - | - | -40°C ~ 50°C | Thermally Protected | Chassis Mount | CSA, UL |
|
|
2730540000SPD TYPE 2 300VAC MCOV 3 POLE |
7,237 |
|
Datasheet |
- | Box | Active | Type 2 | Base + Module | 3 | 300VAC | 20 kA | 50 kA | 200 kA | 1.8 kV | - | -40°C ~ 85°C | - | DIN Rail | CE, cULus, VDE |
