Surge Protection Devices (SPDs)
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Form | Number of Poles | Voltage - Continuous Operating (Max) (MCOV) | Current - Discharge (Nom) (8/20µS) | Current - Discharge (Max) (8/20µS) | Operating Temperature | Voltage - Protection Rating (VPR) | Voltage - Protection Level (VP) (2416) | Operating Temperature | Features | Mounting Type | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SSP057POESE10SPD 48VDC MCOV 1 POLE |
5,868 |
|
Datasheet |
- | Box | Obsolete | - | Module Only | 1 | 48VDC | - | 10 kA | - | 2 kV | - | - | - | Chassis Mount | - |
|
DS74US-120Y/GSPD TYPE 1 300VAC MCOV 1 POLE |
8,090 |
|
- |
- | Active | Type 1 | Base + Module | 1 | 300VAC | 20 kA | 75 kA | 200 kA | 1.5 kV | - | -40°C ~ 85°C | - | DIN Rail | - | |
|
DS73US-120T/GSPD TYPE 1 420VAC MCOV 1 POLE |
4,847 |
|
- |
- | Active | Type 1 | Base + Module | 1 | 420VAC | - | - | 200 kA | 1.5 kV | - | -40°C ~ 85°C | - | DIN Rail | - | |
|
|
2736450000SPD TYPE 2 300VAC MCOV 3 POLE |
5,966 |
|
Datasheet |
- | Box | Active | Type 2 | Base + Module | 3 | 300VAC | 20 kA | 50 kA | 200 kA | 1.8 kV | - | -40°C ~ 85°C | Remote Signaling Contacts | DIN Rail | CE, cULus, VDE |
|
1210-3S-600SPD TYPE 2/TYPE 4 840VAC MCOV |
5,290 |
|
Datasheet |
1210 | Bulk | Active | Type 2, Type 4 | Module Only | 3 | 840VAC | 20 kA | 100 kA | 100 kA | 3 kV | 4 kV | -50°C ~ 85°C | Remote Signaling Contacts, Thermally Protected | DIN Rail | CE, CSA, UL |
|
|
HAW562-AADSPD TYPE 1 MCOV 1 POLE |
6,554 |
|
Datasheet |
HAW562 | Box | Active | Type 1 | Module Only | 1 | - | 10 kA | - | 2.5 kA | - | 550 V | -40°C ~ 80°C | Remote Signaling Contacts, Visual Life Indicator | DIN Rail | - |
|
|
SP1-600DSPD TYPE 1 840V MCOV 1 POLE |
6,897 |
|
- |
SP1 | Bulk | Active | Type 1 | Base + Module | 1 | 840V | 10 kA | - | 200 kA | 2.5 kV | - | -20°C ~ 50°C | Visual Life Indicator | Free Hanging | UL |
|
|
SP1-480YSPD TYPE 1 640V MCOV 1 POLE |
4,823 |
|
- |
SP1 | Bulk | Active | Type 1 | Base + Module | 1 | 640V | 20 kA | - | 200 kA | 2 kV | - | -20°C ~ 50°C | Visual Life Indicator | Free Hanging | UL |
|
|
SP1-208YSPD TYPE 1 300V MCOV 1 POLE |
9,427 |
|
- |
SP1 | Bulk | Active | Type 1 | Base + Module | 1 | 300V | 20 kA | - | 200 kA | 1 kV | - | -20°C ~ 50°C | Visual Life Indicator | Free Hanging | UL |
|
|
SP1-600YSPD TYPE 1 840V MCOV 1 POLE |
6,666 |
|
- |
SP1 | Bulk | Active | Type 1 | Base + Module | 1 | 840V | 10 kA | - | 200 kA | 2.5 kV | - | -20°C ~ 50°C | Visual Life Indicator | Free Hanging | UL |
|
|
SP1-240DSPD 300VAC MCOV 1 POLE |
3,049 |
|
- |
SP1 | Bulk | Active | - | Module Only | 1 | 300VAC | - | 50 kA | - | - | - | - | - | Free Hanging | - |
|
|
SP1-240SSPD TYPE 1 300V MCOV 1 POLE |
9,246 |
|
- |
SP1 | Bulk | Active | Type 1 | Base + Module | 1 | 300V | 20 kA | - | 200 kA | 1 kV | - | -20°C ~ 50°C | Thermally Protected | Chassis Mount | - |
|
|
SP1-480DSPD 640VAC MCOV 1 POLE |
3,085 |
|
- |
SP1 | Bulk | Active | - | Module Only | 1 | 640VAC | - | 50 kA | - | - | - | - | - | - | - |
|
|
HAW562-AAESPD TYPE 1 MCOV 1 POLE |
9,688 |
|
Datasheet |
HAW562 | Box | Active | Type 1 | Module Only | 1 | - | 10 kA | - | 2.5 kA | - | 600 V | -40°C ~ 80°C | Remote Signaling Contacts, Visual Life Indicator | DIN Rail | - |
|
DS44S-120/GSPD TYPE 2 150VAC MCOV 1 POLE |
5,184 |
|
- |
- | Active | Type 2 | Base + Module | 1 | 150VAC | 20 kA | 40 kA | 25 kA | - | 900 V | -40°C ~ 85°C | Remote Signaling Contacts | DIN Rail | CE, EAC, TUV, UR | |
|
DS44S-320SPD TYPE 4 MCOV 1 POLE |
2,858 |
|
- |
- | Active | Type 4 | Base + Module | 1 | - | - | 160 kA | - | - | - | -35°C ~ 60°C | Remote Signaling Contacts | DIN Rail | EAC, UR | |
|
DS44S-480SPD TYPE 1 550VAC MCOV 1 POLE |
4,737 |
|
- |
- | Active | Type 1 | Base + Module | 1 | 550VAC | 20 kA | 40 kA | 100 kA | 4 kV | - | -35°C ~ 60°C | - | DIN Rail | EAC, UR | |
|
DS44S-120SPD TYPE 2 150VAC MCOV 1 POLE |
5,113 |
|
- |
- | Active | Type 2 | Base + Module | 1 | 150VAC | 20 kA | 160 kA | 25 kA | - | 900 V | -40°C ~ 85°C | Remote Signaling Contacts | DIN Rail | CE, EAC, TUV, UR | |
|
DS44S-400SPD TYPE 2 440VAC MCOV 1 POLE |
9,353 |
|
- |
- | Active | Type 2 | Base + Module | 1 | 440VAC | 20 kA | 40 kA | 25 kA | - | 1.8 kV | -40°C ~ 85°C | Remote Signaling Contacts | DIN Rail | CE, EAC, TUV, UR | |
|
DS44S-320/GSPD TYPE 4 MCOV 1 POLE |
5,429 |
|
- |
- | Active | Type 4 | Base + Module | 1 | - | - | 40 kA | - | - | - | -35°C ~ 60°C | - | DIN Rail | - |
