Signal Relays, Up to 2 Amps
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Mounting Type | Coil Voltage | Contact Form | Contact Rating (Current) | Switching Voltage | Load - Max Switching | Coil Current | Coil Type | Features | Termination Style | Seal Rating | Coil Insulation | Must Operate Voltage | Must Release Voltage | Operate Time | Release Time | Operating Temperature | Contact Material | Relay Type | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1-1617016-0RELAY GENERAL PURPOSE DPDT 2A TE Connectivity Aerospace, Defense and Marine |
1,695 |
|
- |
3SBK | Bulk | Active | Through Hole | - | DPDT (2 Form C) | 2 A | 115VAC, 28VDC - Max | - | - | Non Latching | Diode | PC Pin | Sealed - Hermetically | - | - | - | 4 ms | 4 ms | -65°C ~ 125°C | - | General Purpose | - | - |
|
|
1617012-3RELAY TE Connectivity Aerospace, Defense and Marine |
2,779 |
|
- |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
1-1617608-3RELAY TE Connectivity Aerospace, Defense and Marine |
3,810 |
|
- |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
RH4C3H2609RELAY TE Connectivity Aerospace, Defense and Marine |
1,714 |
|
- |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
1616540-7RELAY SPST 1A 28V TE Connectivity Aerospace, Defense and Marine |
4,140 |
|
Datasheet |
QR-50, HARTMAN | Bulk | Active | Chassis Mount | 28VDC | SPST-NC (1 Form B) | 1 A | - | - | - | - | - | Stud | - | - | - | - | - | - | -55°C ~ 71°C | - | - | - | - |
|
LF2149K00RELAY GEN PURPOSE DPDT 2A 26.5V TE Connectivity Aerospace, Defense and Marine |
2,561 |
|
Datasheet |
LF, CII | Bulk | Active | Chassis Mount | 26.5VDC | DPDT (2 Form C) | 2 A | 28VDC - Nom | - | 23 mA | Latching, Dual Coil | - | Solder Hook | - | - | 13.5 VDC | - | 5 ms | 5 ms | -65°C ~ 125°C | - | General Purpose | - | - |
|
|
6-1617521-7RELAY GENERAL PURPOSE DPDT 2A TE Connectivity Aerospace, Defense and Marine |
3,384 |
|
- |
3SAE, CII | Bulk | Active | Chassis Mount | - | DPDT (2 Form C) | 2 A | 115VAC, 28VDC - Max | 230VA, 56W | - | Non Latching | - | Solder Hook | Sealed - Hermetically | - | - | - | 6 ms | 5 ms | -65°C ~ 125°C | - | General Purpose | - | - |
|
|
3SAM6154N2RELAY GEN PURPOSE DPDT 2A 32V TE Connectivity Aerospace, Defense and Marine |
4,239 |
|
Datasheet |
3SAM, CII | Bulk | Active | Chassis Mount | 32VDC | DPDT (2 Form C) | 2 A | 115VAC, 28VDC - Nom | - | 21.3 mA | Latching, Dual Coil | - | Solder Hook | Sealed - Hermetically | - | - | - | 4 ms | 2 ms | -65°C ~ 125°C | - | General Purpose | - | - |
|
|
2-1617088-2RELAY GEN PURPOSE DPDT 2A 26.5V TE Connectivity Aerospace, Defense and Marine |
2,041 |
|
- |
3SAM, CII | Bulk | Active | Chassis Mount | 26.5VDC | DPDT (2 Form C) | 2 A | 115VAC, 28VDC - Nom | - | 27.2 mA | Latching, Dual Coil | - | PC Pin | Sealed - Hermetically | - | - | - | 4 ms | 2 ms | -65°C ~ 125°C | - | General Purpose | - | - |
|
|
2-1617088-3RELAY GEN PURPOSE DPDT 2A 28V TE Connectivity Aerospace, Defense and Marine |
4,491 |
|
- |
3SAM, CII | Bulk | Active | Chassis Mount | 28VDC | DPDT (2 Form C) | 2 A | 115VAC, 28VDC - Nom | - | 18.7 mA | Latching, Dual Coil | - | PC Pin | Sealed - Hermetically | - | - | - | 4 ms | 2 ms | -65°C ~ 125°C | - | General Purpose | - | - |
