Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CTH7F-151K150UH AXIAL PWR LINE INDUCTOR Central Technologies |
370 |
|
Datasheet |
CTH7F | Axial | Tape & Reel (TR) | Active | - | - | 150 µH | ±10% | 510 mA | 1A | Unshielded | 340mOhm Max | - | 3MHz | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Axial | 0.290" Dia x 0.602" L (7.37mm x 15.30mm) | - |
|
|
CTH7F-4R7K4.7UH AXIAL PWR LINE INDUCTOR Central Technologies |
366 |
|
Datasheet |
CTH7F | Axial | Tape & Reel (TR) | Active | - | - | 4.7 µH | ±10% | 1.3 A | 6.3A | Unshielded | 20mOhm Max | - | 26MHz | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Axial | 0.290" Dia x 0.602" L (7.37mm x 15.30mm) | - |
|
|
CTH7F-3R9K3.9UH AXIAL PWR LINE INDUCTOR Central Technologies |
330 |
|
Datasheet |
CTH7F | Axial | Tape & Reel (TR) | Active | - | - | 3.9 µH | ±10% | 1.3 A | 7.3A | Unshielded | 20mOhm Max | - | 38MHz | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Axial | 0.290" Dia x 0.602" L (7.37mm x 15.30mm) | - |
|
|
CTH7F-5R6K5.6UH AXIAL PWR LINE INDUCTOR Central Technologies |
288 |
|
Datasheet |
CTH7F | Axial | Tape & Reel (TR) | Active | - | - | 5.6 µH | ±10% | 1.3 A | 5.6A | Unshielded | 20mOhm Max | - | 25MHz | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Axial | 0.290" Dia x 0.602" L (7.37mm x 15.30mm) | - |
|
|
CTH7F-682K6800UH AXIAL PWR LINE INDUCTOR Central Technologies |
156 |
|
Datasheet |
CTH7F | Axial | Tape & Reel (TR) | Active | - | - | 6.8 mH | ±10% | 80 mA | 150mA | Unshielded | 16Ohm Max | - | 400kHz | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Axial | 0.290" Dia x 0.602" L (7.37mm x 15.30mm) | - |
|
CTRL5480F-5-274K27000UH RADIAL FIXED INDUCTR Central Technologies |
287 |
|
- |
CTRL5480F-5 | Radial, Vertical Cylinder | Bulk | Active | - | - | 270 mH | ±10% | 60 mA | 39mA | Unshielded | 174Ohm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial | 0.626" Dia (15.90mm) | 0.701" (17.80mm) |
|
CTDR1F-150K15UH RADIAL DRUM CORE INDUCTOR Central Technologies |
500 |
|
Datasheet |
CTDR1F | Radial, Vertical Cylinder | Bulk | Active | Drum Core, Wirewound | - | 15 µH | ±10% | - | 7.2A | Unshielded | 15mOhm Max | - | - | - | -25°C ~ 85°C | 1 kHz | - | Through Hole | Radial, Vertical Cylinder | 0.669" Dia (17.00mm) | 0.866" (22.00mm) |
|
CTH8RF-271K270UH RADIAL PWR LINE INDUCTOR Central Technologies |
303 |
|
Datasheet |
CTH8RF | Radial, Vertical Cylinder | Bulk | Active | - | - | 270 µH | ±10% | 1.6 A | 1.6A | Unshielded | 210mOhm Max | - | 2MHz | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial | 0.469" Dia (11.90mm) | 0.917" (23.30mm) |
|
|
CTH8RF-101K100UH RADIAL PWR LINE INDUCTOR Central Technologies |
228 |
|
Datasheet |
CTH8RF | Radial, Vertical Cylinder | Bulk | Active | - | - | 100 µH | ±10% | 1.6 A | 2.8A | Unshielded | 90mOhm Max | - | 3MHz | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial | 0.469" Dia (11.90mm) | 0.917" (23.30mm) |
|
CTS4F-103K100UH AXIAL SHELDED INDUCTR Central Technologies |
1,972 |
|
Datasheet |
CTS4F | Axial | Tape & Reel (TR) | Active | Molded | - | 10 mH | ±10% | 50 mA | 14mA | Shielded | 93Ohm Max | 70 @ 250kHz | 1.3MHz | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Axial | 0.160" Dia x 0.449" L (4.06mm x 11.40mm) | - |
