Electric Actuators/Cylinders
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Motor Type | Stroke Length | Load Force (Dynamic) | Load Force (Static) | Speed | Duty Cycle | Voltage - Rated | Construction | Accuracy | Acceleration | Features | Gear Reduction Ratio | Feedback Type | Termination Style | Operating Temperature | Ingress Protection | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
2309LINEAR ACTUATOR MOTOR 12V |
4,249 |
|
Datasheet |
Glideforce | - | Active | Linear Actuator | Brushed | 8.000" (203.20mm) | 112.40lbf (500.0N) | 562.02lbf (2500.0N) | 0.57 in/s (14.5 mm/s) | 25% | 12VDC | Ball Screw | - | - | Limit Switches | 20 | Potentiometer | Cable with Connector | -25°C ~ 65°C | IP65 - Dust Tight, Water Resistant | - |
|
2327LINEAR ACTUATOR MOTOR 12V |
4,824 |
|
Datasheet |
Glideforce | - | Active | Linear Actuator | Brushed | 12.000" (304.80mm) | 33.72lbf (150.0N) | 562.02lbf (2500.0N) | 1.73 in/s (43.9 mm/s) | 25% | 12VDC | Ball Screw | - | - | Limit Switches | 5 | Potentiometer | Cable with Connector | -25°C ~ 65°C | IP65 - Dust Tight, Water Resistant | - |
|
2305LINEAR ACTUATOR MOTOR 12V |
4,591 |
|
Datasheet |
Glideforce | - | Active | Linear Actuator | Brushed | 4.000" (101.60mm) | 112.40lbf (500.0N) | 562.02lbf (2500.0N) | 0.57 in/s (14.5 mm/s) | 25% | 12VDC | Ball Screw | - | - | Limit Switches | 20 | Potentiometer | Cable with Connector | -25°C ~ 65°C | IP65 - Dust Tight, Water Resistant | - |
|
3653LINEAR ACTUATOR MOTOR 12V |
3,205 |
|
Datasheet |
Glideforce | - | Active | Linear Actuator | Brushed | 12.000" (304.80mm) | 56.20lbf (250.0N) | 562.02lbf (2500.0N) | 1.10 in/s (28.0 mm/s) | 25% | 12VDC | Ball Screw | - | - | Limit Switches | 10 | Potentiometer | Cable with Connector | -25°C ~ 65°C | IP65 - Dust Tight, Water Resistant | - |
|
|
2307SERVOMOTOR RC 6V GLIDEFORCE |
2,889 |
|
Datasheet |
Glideforce | - | Active | Linear Actuator | Brushed | 6.000" (152.40mm) | 112.40lbf (500.0N) | 562.02lbf (2500.0N) | 0.57 in/s (14.5 mm/s) | 25% | 12VDC | Ball Screw | - | - | Limit Switches | 20 | Potentiometer | Cable with Connector | -25°C ~ 65°C | IP65 - Dust Tight, Water Resistant | - |
|
2317LINEAR ACTUATOR MOTOR 12V |
2,586 |
|
Datasheet |
Glideforce | - | Active | Linear Actuator | Brushed | 2.000" (50.80mm) | 33.72lbf (150.0N) | 562.02lbf (2500.0N) | 1.73 in/s (43.9 mm/s) | 25% | 12VDC | Ball Screw | - | - | Limit Switches | 5 | Potentiometer | Cable with Connector | -25°C ~ 65°C | IP65 - Dust Tight, Water Resistant | - |
|
2325LINEAR ACTUATOR MOTOR 12V |
3,264 |
|
Datasheet |
Glideforce | - | Active | Linear Actuator | Brushed | 10.000" (254.00mm) | 33.72lbf (150.0N) | 562.02lbf (2500.0N) | 1.73 in/s (43.9 mm/s) | 25% | 12VDC | Ball Screw | - | - | Limit Switches | 5 | Potentiometer | Cable with Connector | -25°C ~ 65°C | IP65 - Dust Tight, Water Resistant | - |
|
3645LINEAR ACTUATOR MOTOR 12V |
3,563 |
|
Datasheet |
Glideforce | - | Active | Linear Actuator | Brushed | 4.000" (101.60mm) | 56.20lbf (250.0N) | 562.02lbf (2500.0N) | 1.10 in/s (28.0 mm/s) | 25% | 12VDC | Ball Screw | - | - | Limit Switches | 10 | Potentiometer | Cable with Connector | -25°C ~ 65°C | IP65 - Dust Tight, Water Resistant | - |
|
3651LINEAR ACTUATOR MOTOR 12V |
3,023 |
|
Datasheet |
Glideforce | - | Active | Linear Actuator | Brushed | 10.000" (254.00mm) | 56.20lbf (250.0N) | 562.02lbf (2500.0N) | 1.10 in/s (28.0 mm/s) | 25% | 12VDC | Ball Screw | - | - | Limit Switches | 10 | Potentiometer | Cable with Connector | -25°C ~ 65°C | IP65 - Dust Tight, Water Resistant | - |
|
|
2311LINEAR ACTUATOR MOTOR 12V |
3,679 |
|
Datasheet |
Glideforce | - | Active | Linear Actuator | Brushed | 10.000" (254.00mm) | 112.40lbf (500.0N) | 562.02lbf (2500.0N) | 0.57 in/s (14.5 mm/s) | 25% | 12VDC | Ball Screw | - | - | Limit Switches | 20 | Potentiometer | Cable with Connector | -25°C ~ 65°C | IP65 - Dust Tight, Water Resistant | - |
|
2313LINEAR ACTUATOR MOTOR 12V |
4,810 |
|
Datasheet |
Glideforce | - | Active | Linear Actuator | Brushed | 12.000" (304.80mm) | 112.40lbf (500.0N) | 562.02lbf (2500.0N) | 0.57 in/s (14.5 mm/s) | 25% | 12VDC | Ball Screw | - | - | Limit Switches | 20 | Potentiometer | Cable with Connector | -25°C ~ 65°C | IP65 - Dust Tight, Water Resistant | - |
|
2321LINEAR ACTUATOR MOTOR 12V |
4,014 |
|
Datasheet |
Glideforce | - | Active | Linear Actuator | Brushed | 6.000" (152.40mm) | 33.72lbf (150.0N) | 562.02lbf (2500.0N) | 1.73 in/s (43.9 mm/s) | 25% | 12VDC | Ball Screw | - | - | Limit Switches | 5 | Potentiometer | Cable with Connector | -25°C ~ 65°C | IP65 - Dust Tight, Water Resistant | - |
|
|
2323LINEAR ACTUATOR MOTOR 12V |
4,642 |
|
Datasheet |
Glideforce | - | Active | Linear Actuator | Brushed | 8.000" (203.20mm) | 33.72lbf (150.0N) | 562.02lbf (2500.0N) | 1.73 in/s (43.9 mm/s) | 25% | 12VDC | Ball Screw | - | - | Limit Switches | 5 | Potentiometer | Cable with Connector | -25°C ~ 65°C | IP65 - Dust Tight, Water Resistant | - |
|
|
3643LINEAR ACTUATOR MOTOR 12V |
2,167 |
|
Datasheet |
Glideforce | - | Active | Linear Actuator | Brushed | 2.000" (50.80mm) | 56.20lbf (250.0N) | 562.02lbf (2500.0N) | 1.10 in/s (28.0 mm/s) | 25% | 12VDC | Ball Screw | - | - | Limit Switches | 10 | Potentiometer | Cable with Connector | -25°C ~ 65°C | IP65 - Dust Tight, Water Resistant | - |
|
|
3647LINEAR ACTUATOR MOTOR 12V |
3,909 |
|
Datasheet |
Glideforce | - | Active | Linear Actuator | Brushed | 6.000" (152.40mm) | 56.20lbf (250.0N) | 562.02lbf (2500.0N) | 1.10 in/s (28.0 mm/s) | 25% | 12VDC | Ball Screw | - | - | Limit Switches | 10 | Potentiometer | Cable with Connector | -25°C ~ 65°C | IP65 - Dust Tight, Water Resistant | - |
|
3649LINEAR ACTUATOR MOTOR 12V |
4,043 |
|
Datasheet |
Glideforce | - | Active | Linear Actuator | Brushed | 8.000" (203.20mm) | 56.20lbf (250.0N) | 562.02lbf (2500.0N) | 1.10 in/s (28.0 mm/s) | 25% | 12VDC | Ball Screw | - | - | Limit Switches | 10 | Potentiometer | Cable with Connector | -25°C ~ 65°C | IP65 - Dust Tight, Water Resistant | - |
|
12LF-17F-53Micro/Mini Linear Servo Actuator |
1,340 |
|
Datasheet |
12Lf (Servo) | Box | Active | Linear Actuator | Brushed (Coreless) | 2.087" (53.00mm) | 7.64lbf (34.0N) | - | 3.64 in/s (92.4 mm/s) | 50% | 12VDC | Lead Screw | 40µm | - | Integrated Controller | 10 | Potentiometer | Cable with Connector | -10°C ~ 60°C | IP54 - Dust Protected, Water Resistant | CE |
|
|
12LF-78F-53Micro/Mini Linear Servo Actuator |
1,243 |
|
Datasheet |
12Lf (Servo) | Box | Active | Linear Actuator | Brushed (Coreless) | 2.087" (53.00mm) | 35.07lbf (156.0N) | - | 0.34 in/s (8.5 mm/s) | 50% | 12VDC | Lead Screw | 40µm | - | Integrated Controller | 50 | Potentiometer | Cable with Connector | -10°C ~ 60°C | IP54 - Dust Protected, Water Resistant | CE |
|
12LF-17F-90Micro/Mini Linear Servo Actuator |
4,611 |
|
Datasheet |
12Lf (Servo) | Box | Active | Linear Actuator | Brushed (Coreless) | 3.563" (90.50mm) | 7.64lbf (34.0N) | - | 3.64 in/s (92.4 mm/s) | 50% | 12VDC | Lead Screw | 50µm | - | Integrated Controller | 10 | Potentiometer | Cable with Connector | -10°C ~ 60°C | IP54 - Dust Protected, Water Resistant | CE |
|
3613LINEAR ACTUATOR MOTOR 12V |
3,428 |
|
Datasheet |
Glideforce | - | Active | Linear Actuator | Brushed | 4.000" (101.60mm) | 224.81lbf (1000.0N) | 1011.64lbf (4500.0N) | 0.58 in/s (14.7 mm/s) | 25% | 12VDC | Ball Screw | - | - | Limit Switches | 20 | - | Cable with Connector | -25°C ~ 65°C | IP65 - Dust Tight, Water Resistant | - |
