Signal Transformer 56-50

Part No.:
56-50
Manufacturer:
Signal Transformer
Category:
Power Transformers
Package:
Datasheet:
Shenzhen JiaYouSheng Electronics Co., Ltd.56-50.pdf
Description:
PWR XFMR LAMINATED 288VA CHAS MT
Quantity:
Payment:
Payment
Shipping:
Shipping

Inventory:4,197

Please send an inquiry. Send us your inquiry, and we will respond immediately.

Part Number
Quantity*
Price
Name*
Company*
Email*
Comments
  • Specifications
  • FAQ
  • Product Comparison
  • Tags
Product attributes
Attribute value
Manufacturer:
Signal Transformer
Series:
-
Packaging:
Box
Product Status:
Active
Type:
Laminated Core
Voltage - Primary:
105V, 115V, 125V, 230V
Voltage - Secondary (Full Load):
Parallel 28V, Series 56V
Current - Output (Max):
Parallel 100A, Series 50A
Primary Winding(s):
Dual
Secondary Winding(s):
Dual
Center Tap:
Yes
Power - Max:
288VA
Mounting Type:
Chassis Mount
Termination Style:
Solder, Quick Connect
Size / Dimension:
190.50mm L x 190.50mm W
Height - Seated (Max):
158.80mm
Voltage - Isolation:
1500Vrms
Weight:
57 lbs (25.9 kg)
