Toggle Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Mounting Type | Circuit | Switch Function | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Actuator Type | Actuator Length | Illumination | Illumination Type, Color | Illumination Voltage (Nominal) | Termination Style | Panel Cutout Dimensions | Bushing Thread | Ingress Protection | Features | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
AML25GBF3AA02GRSWITCH TOGGLE SPDT 3A 125V Honeywell Sensing and Productivity Solutions |
4,920 |
|
- |
AML25 | Bulk | Obsolete | Panel Mount, Snap-In | SPDT | On-Mom | 3A (AC), 2A (DC) | 125 V | 24 V | Paddle | - | Illuminated | LED, Green/Red | 24 VDC | PC Pin | Rectangular - 28.98mm x 19.05mm | - | - | - | - |
|
|
1TW1-5SWITCH TOGGLE SPDT 5A 125V Honeywell Sensing and Productivity Solutions |
4,203 |
|
Datasheet |
TW | Bulk | Obsolete | Panel Mount | SPDT | On-Off-Mom | 5A (AC/DC) | 125 V | 28 V | Standard Round | 10.67mm | Non-Illuminated | - | - | Solder Turret | Circular - 6.60mm Dia | 1/4-40 | Environment Sealed | - | -65°C ~ 71°C |
|
|
14TL1-12SWITCH TOGGLE 4PDT 15A 125V Honeywell Sensing and Productivity Solutions |
3,773 |
|
Datasheet |
TL | Bulk | Active | Panel Mount | 4PDT | On-On-On | 15A (AC) | 125 V | - | Standard Round | 17.27mm | Non-Illuminated | - | - | Solder Turret | Circular - 12.40mm Dia | 15/32-32 | Environment Sealed | - | -65°C ~ 71°C |
|
|
2TL11-50SWITCH TOGGLE DPDT 11A 125V Honeywell Sensing and Productivity Solutions |
3,328 |
|
Datasheet |
TL | Bulk | Active | Panel Mount | DPDT | On-On-Mom | 11A (AC), 18A (DC) | 125 V | 28 V | Standard Round | 17.27mm | Non-Illuminated | - | - | Screw Terminal | Circular - 12.40mm Dia | 15/32-32 | Environment Sealed | - | -65°C ~ 71°C |
|
|
12TW401-7SWITCH TOGGLE DPDT 5A 125V Honeywell Sensing and Productivity Solutions |
2,208 |
|
Datasheet |
TW | Bulk | Active | Panel Mount | DPDT | Mom-Off-Mom | 5A (AC) | 125 V | - | Flatted | 17.27mm | Non-Illuminated | - | - | Solder Turret | Circular - 12.40mm Dia | 15/32-32 | Environment Sealed | - | -65°C ~ 71°C |
|
2TL1-50MSWITCH TOGGLE DPDT 10A 125V Honeywell Sensing and Productivity Solutions |
2,761 |
|
Datasheet |
TL | Bulk | Active | Panel Mount | DPDT | On-On-Mom | 10A (AC) | 125 V | - | Locking Lever | 26.67mm | Non-Illuminated | - | - | Screw Terminal | Circular - 12.40mm Dia | 15/32-32 | Environment Sealed | - | -65°C ~ 71°C |
|
2TL1-50ESWITCH TOGGLE DPDT 10A 125V Honeywell Sensing and Productivity Solutions |
1,306 |
|
Datasheet |
TL | Bulk | Active | Panel Mount | DPDT | On-On-Mom | 10A (AC) | 125 V | - | Locking Lever | 26.67mm | Non-Illuminated | - | - | Screw Terminal | Circular - 12.40mm Dia | 15/32-32 | Environment Sealed | - | -65°C ~ 71°C |
|
|
2TL5-2SWITCH TOGGLE DPST 15A 125V Honeywell Sensing and Productivity Solutions |
1,814 |
|
Datasheet |
TL | Bulk | Active | Panel Mount | DPST | On-Off | 15A (AC) | 125 V | - | Standard Round | 17.27mm | Non-Illuminated | - | - | Screw Terminal | Circular - 12.40mm Dia | 15/32-32 | Environment Sealed | - | -65°C ~ 71°C |
|
|
2TL11-6FSWITCH TOGGLE DPST-NO 10A 125V Honeywell Sensing and Productivity Solutions |
4,140 |
|
Datasheet |
TL | Bulk | Active | Panel Mount | DPST-NO | Off-Mom | 10A (AC) | 125 V | - | Standard Round | 17.27mm | Non-Illuminated | - | - | Screw Terminal | Circular - 12.40mm Dia | 15/32-32 | Environment Sealed | - | -65°C ~ 71°C |
|
|
1TL62-6SWITCH TOGGLE SPST-NO 10A 125V Honeywell Sensing and Productivity Solutions |
2,260 |
|
Datasheet |
TL | Bulk | Active | Panel Mount | SPST-NO | Off-Mom | 10A (AC) | 125 V | - | Flatted | 16.51mm | Non-Illuminated | - | - | Screw Terminal | Circular - 12.40mm Dia | 15/32-32 | Environment Sealed | - | -65°C ~ 71°C |
