Stepper Motors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Coil Type | Voltage - Rated | Current Rating (Amps) | Steps per Revolution | Step Angle | Accuracy | Torque - Holding (oz-in / mNm) | Size / Dimension | NEMA Frame Size | Diameter - Shaft | Length - Shaft and Bearing | Mounting Hole Spacing | Termination Style | Operating Temperature | Coil Resistance | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
42M048C1B-Z36STEP MOTOR PM GEARED BIPOLAR 5V |
3,414 |
|
Datasheet |
42M-Z | Bulk | Obsolete | Permanent Magnet Gear Motor | Bipolar | 5VDC | 550 mA | 2400.0 | 0.15° | - | 11.9 / 84 | Round - 1.650" Dia (42.00mm) | - | 0.188" (4.77mm) | 0.500" (12.70mm) | 1.880" (47.63mm) | Wire Leads | -20°C ~ 70°C | 9.1 Ohms | Round Shaft |
|
17H018D10BSTEP MOTOR HYBRID BIPOLAR 3.3V |
4,712 |
|
Datasheet |
H3 | Bulk | Obsolete | Hybrid | Bipolar | 3.3VDC | 1 A | 200.0 | 1.8° | ±5% | 30 / 212 | Square - 1.680" x 1.680" (42.67mm x 42.67mm) | 17 | 0.197" (5.00mm) | 0.790" (20.07mm) | 1.220" (30.99mm) | Wire Leads | -20°C ~ 40°C | 3.32 Ohms | Round Shaft |
|
17H118D10BSTEP MOTOR HYBRID BIPOLAR 4.1V |
4,321 |
|
Datasheet |
H3 | Bulk | Obsolete | Hybrid | Bipolar | 4.1VDC | 1 A | 200.0 | 1.8° | ±5% | 51 / 360 | Square - 1.680" x 1.680" (42.67mm x 42.67mm) | 17 | 0.197" (5.00mm) | 0.790" (20.07mm) | 1.220" (30.99mm) | Wire Leads | -20°C ~ 40°C | 4.12 Ohms | Round Shaft |
|
23H018D10BSTEP MOTOR HYBRID BIPOLAR 5.7V |
2,469 |
|
Datasheet |
H3 | Bulk | Obsolete | Hybrid | Bipolar | 5.7VDC | 1 A | 200.0 | 1.8° | ±5% | 75 / 530 | Square - 2.250" x 2.250" (57.15mm x 57.15mm) | 23 | 0.250" (6.35mm) | 0.810" (20.57mm) | 1.856" (47.14mm) | Wire Leads | -20°C ~ 40°C | 5.7 Ohms | Round Shaft |
|
23H118D10BSTEP MOTOR HYBRID BIPOLAR 6.84V |
2,382 |
|
Datasheet |
H3 | Bulk | Obsolete | Hybrid | Bipolar | 6.84VDC | 1 A | 200.0 | 1.8° | ±5% | 180 / 1271 | Square - 2.250" x 2.250" (57.15mm x 57.15mm) | 23 | 0.250" (6.35mm) | 0.810" (20.57mm) | 1.856" (47.14mm) | Wire Leads | -20°C ~ 40°C | 6.84 Ohms | Round Shaft |
|
42M048C1B-R16STEP MOTOR PM GEARED BIPOLAR 5V |
3,505 |
|
Datasheet |
42M-R | Bulk | Active | Permanent Magnet Gear Motor | Bipolar | 5VDC | 550 mA | 240.0 | 1.5° | - | 11.9 / 84 | Round - 1.650" Dia (42.00mm) | - | 0.093" (2.36mm) | 0.469" (11.92mm) | 1.880" (47.63mm) | Wire Leads | -20°C ~ 70°C | 9.1 Ohms | Round Shaft |
|
82910008STEPPER MOTOR 4PH 115OHM PAL 9AX |
1,378 |
|
- |
82910 | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
82914038STEPPER MOTOR 4PH 15.5OHM 80:1 |
3,374 |
|
- |
82914 | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
23KM-K041BT03CASTEPPER MOTOR HYBRID BIPOLAR 36V |
3,737 |
|
Datasheet |
23KM | Box | Obsolete | Hybrid | Bipolar | 36VDC | - | 200.0 | 1.8° | ±5% | 169.53 / 1197 | Square - 2.220" x 2.220" (56.40mm x 56.40mm) | 23 | 0.236" (6.00mm) | 0.453" (11.50mm) | 1.856" (47.14mm) | Wire Leads | - | 1 Ohms | Flatted Shaft |
|
23KM-K249BT04CASTEPPER MOTOR HYBRID BIPOLAR 24V |
3,564 |
|
Datasheet |
23KM | Box | Obsolete | Hybrid | Bipolar | 24VDC | - | 200.0 | 1.8° | ±5% | 76.5 / 540 | Square - 2.220" x 2.220" (56.40mm x 56.40mm) | 23 | 0.315" (8.00mm) | 0.551" (14.00mm) | 1.856" (47.14mm) | Wire Leads | - | 2.4 Ohms | Flatted Shaft |
|
10PM-K405CT01CNSTEPPER MOTOR HYBRID BIPOLAR 24V |
1,609 |
|
Datasheet |
10PM | Box | Obsolete | Hybrid | Bipolar | 24VDC | 1.5 A | 200.0 | 1.8° | - | 17 / 120 | Square - 0.984" x 0.984" (25.00mm x 25.00mm) | 10 | 0.197" (5.00mm) | 0.394" (10.00mm) | 0.787" (20.00mm) | Connector | - | 1.6 Ohms | Round Shaft |
|
14PM-M144BSTEP MOTOR HYBRID UNIPOLAR 24V |
4,352 |
|
Datasheet |
14PM | Bulk | Obsolete | Hybrid | Bipolar | 24VDC | 850 mA | 200.0 | 1.8° | - | 24.93 / 176 | Square - 1.378" x 1.378" (35.00mm x 35.00mm) | 14 | 0.197" (5.00mm) | 0.984" (25.00mm) | 1.023" (26.00mm) | Wire Leads with Connector | - | 5.4 Ohms | Round Shaft |
|
|
14PM-M444BSTEP MOTOR HYBRID UNIPOLAR 24V |
3,935 |
|
Datasheet |
14PM | Bulk | Obsolete | Hybrid | Bipolar | 24VDC | 700 mA | 200.0 | 1.8° | - | 31.87 / 225 | Square - 1.378" x 1.378" (35.00mm x 35.00mm) | 14 | 0.197" (5.00mm) | 0.984" (25.00mm) | 1.023" (26.00mm) | Wire Leads with Connector | - | 8 Ohms | Round Shaft |
|
|
14PM-M047USTEP MOTOR HYBRID UNIPOLAR 24V |
1,620 |
|
Datasheet |
14PM | Bulk | Obsolete | Hybrid | Unipolar | 24VDC | 800 mA | 200.0 | 1.8° | - | 4.82 / 34 | Square - 1.378" x 1.378" (35.00mm x 35.00mm) | 14 | 0.197" (5.00mm) | 0.787" (20.00mm) | 1.023" (26.00mm) | Wire Leads with Connector | - | 2.4 Ohms | Round Shaft |
|
|
14PM-M144USTEP MOTOR HYBRID UNIPOLAR 24V |
3,296 |
|
Datasheet |
14PM | Bulk | Obsolete | Hybrid | Unipolar | 24VDC | 1 A | 200.0 | 1.8° | - | 17.71 / 125 | Square - 1.378" x 1.378" (35.00mm x 35.00mm) | 14 | 0.197" (5.00mm) | 0.787" (20.00mm) | 1.023" (26.00mm) | Wire Leads with Connector | - | 2.7 Ohms | Round Shaft |
|
|
14PM-M444USTEP MOTOR HYBRID UNIPOLAR 24V |
2,621 |
|
Datasheet |
14PM | Bulk | Obsolete | Hybrid | Unipolar | 24VDC | 1 A | 200.0 | 1.8° | - | 26.91 / 190 | Square - 1.378" x 1.378" (35.00mm x 35.00mm) | 14 | 0.197" (5.00mm) | 0.787" (20.00mm) | 1.023" (26.00mm) | Wire Leads with Connector | - | 4 Ohms | Round Shaft |
|
17PM-Z149USTEP MOTOR HYBRID UNIPOLAR 24V |
2,218 |
|
Datasheet |
17PM | Bulk | Obsolete | Hybrid | Unipolar | 24VDC | 1 A | 200.0 | 1.8° | - | 42.49 / 300 | Square - 1.654" x 1.654" (42.00mm x 42.00mm) | 17 | 0.197" (5.00mm) | 0.945" (24.00mm) | 1.220" (31.00mm) | Connector | - | 4.3 Ohms | Round Shaft |
|
|
17PM-Z342BSTEPPER MOTOR HYBRID BIPOLAR 24V |
2,225 |
|
Datasheet |
17PM | Bulk | Obsolete | Hybrid | Bipolar | 24VDC | 1.4 A | 200.0 | 1.8° | - | 48.15 / 340 | Square - 1.654" x 1.654" (42.00mm x 42.00mm) | 17 | 0.197" (5.00mm) | 0.945" (24.00mm) | 1.220" (31.00mm) | Connector | - | 4 Ohms | Round Shaft |
|
|
82910029MOTOR 829100 -75 SENS=2 PHASE=4 |
3,472 |
|
Datasheet |
82910 | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
14PM-F647ENVA3672STEP MOTOR HYBRID 24V BIPOLAR |
1,685 |
|
Datasheet |
14PM | Bulk | Obsolete | Hybrid | Bipolar | 24VDC | 1.5 A | 200.0 | 1.8° | - | 18.41 / 130 | Square - 1.378" x 1.378" (35.00mm x 35.00mm) | 14 | 0.197" (5.00mm) | 0.787" (20.00mm) | 1.142" (29.00mm) | Wire Leads with Connector | - | 1.2 Ohms | Round Shaft |
