Signal Relays, Up to 2 Amps
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Mounting Type | Coil Voltage | Contact Form | Contact Rating (Current) | Switching Voltage | Load - Max Switching | Coil Current | Coil Type | Features | Termination Style | Seal Rating | Coil Insulation | Must Operate Voltage | Must Release Voltage | Operate Time | Release Time | Operating Temperature | Contact Material | Relay Type | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
G6SK-2F-H DC3RELAY TELECOM DPDT 2A 3V |
3,741 |
|
Datasheet |
G6S | Tube | Active | Surface Mount | 3VDC | DPDT (2 Form C) | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 46.7 mA | Latching, Dual Coil | - | Gull Wing | - | - | 2.25 VDC | - | 4 ms | 4 ms | -40°C ~ 85°C | Silver (Ag), Gold (Au) | Telecom | - | - |
|
|
G6SK-2F-H-TRDC2.4RELAY TELECOM DPDT 2A 2.4V |
2,234 |
|
Datasheet |
G6S | Tape & Reel (TR) | Active | Surface Mount | 2.4VDC | DPDT (2 Form C) | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 58.3 mA | Latching, Dual Coil | - | Gull Wing | - | - | 1.8 VDC | - | 4 ms | 4 ms | -40°C ~ 85°C | Silver (Ag), Gold (Au) | Telecom | - | - |
|
|
G6SK-2F-H-TR DC3RELAY TELECOM DPDT 2A 3V |
2,948 |
|
Datasheet |
G6S | Tape & Reel (TR) | Active | Surface Mount | 3VDC | DPDT (2 Form C) | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 46.7 mA | Latching, Dual Coil | - | Gull Wing | - | - | 2.25 VDC | - | 4 ms | 4 ms | -40°C ~ 85°C | Silver (Ag), Gold (Au) | Telecom | - | - |
|
|
G6SK-2F-TR DC3RELAY TELECOM DPDT 2A 3V |
3,037 |
|
Datasheet |
G6S | Tape & Reel (TR) | Active | Surface Mount | 3VDC | DPDT (2 Form C) | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 66.7 mA | Latching, Dual Coil | - | Gull Wing | - | - | 2.25 VDC | - | 4 ms | 4 ms | -40°C ~ 85°C | Silver (Ag), Gold (Au) | Telecom | - | - |
|
G6SK-2G-H DC4.5RELAY TELECOM DPDT 2A 4.5V |
1,342 |
|
Datasheet |
G6S | Tube | Active | Surface Mount | 4.5VDC | DPDT (2 Form C) | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 31 mA | Latching, Dual Coil | - | J Lead | - | - | 3.38 VDC | - | 4 ms | 4 ms | -40°C ~ 85°C | Silver (Ag), Gold (Au) | Telecom | - | - |
|
|
G6SK-2G-H DC5RELAY TELECOM DPDT 2A 5V |
4,599 |
|
Datasheet |
G6S | Tube | Active | Surface Mount | 5VDC | DPDT (2 Form C) | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 28.1 mA | Latching, Dual Coil | - | J Lead | - | - | 3.75 VDC | - | 4 ms | 4 ms | -40°C ~ 85°C | Silver (Ag), Gold (Au) | Telecom | - | - |
|
|
G6SK-2G-H-TR DC5RELAY TELECOM DPDT 2A 5V |
1,972 |
|
Datasheet |
G6S | Tape & Reel (TR) | Active | Surface Mount | 5VDC | DPDT (2 Form C) | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 28.1 mA | Latching, Dual Coil | - | J Lead | - | - | 3.75 VDC | - | 4 ms | 4 ms | -40°C ~ 85°C | Silver (Ag), Gold (Au) | Telecom | - | - |
|
G6SK-2-H DC24RELAY TELECOM DPDT 2A 24V |
3,062 |
|
Datasheet |
G6S | Tube | Active | Through Hole | 24VDC | DPDT (2 Form C) | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 8.3 mA | Latching, Dual Coil | - | PC Pin | - | - | 18 VDC | - | 4 ms | 4 ms | -40°C ~ 70°C | Silver (Ag), Gold (Au) | Telecom | - | - |
|
|
G6SU-2-3DC5RELAY TELECOM DPDT 2A 5V |
4,396 |
|
Datasheet |
G6S | Tube | Active | Through Hole | 5VDC | DPDT (2 Form C) | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 20 mA | Latching, Single Coil | - | PC Pin | - | - | 3.75 VDC | - | 4 ms | 4 ms | -40°C ~ 85°C | Silver (Ag), Gold (Au) | Telecom | - | - |
|
|
G6SU-2 DC6RELAY TELECOM DPDT 2A 6V |
3,793 |
|
Datasheet |
G6S | Tube | Active | Through Hole | 6VDC | DPDT (2 Form C) | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 16.7 mA | Latching, Single Coil | - | PC Pin | - | - | 4.5 VDC | - | 4 ms | 4 ms | -40°C ~ 85°C | Silver (Ag), Gold (Au) | Telecom | - | - |
|
|
G6SU-2 DC9RELAY TELECOM DPDT 2A 9V |
4,777 |
|
Datasheet |
G6S | Tube | Active | Through Hole | 9VDC | DPDT (2 Form C) | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 11.1 mA | Latching, Single Coil | - | PC Pin | - | - | 6.75 VDC | - | 4 ms | 4 ms | -40°C ~ 85°C | Silver (Ag), Gold (Au) | Telecom | - | - |
|
G6SU-2F DC4.5RELAY TELECOM DPDT 2A 4.5V |
3,507 |
|
Datasheet |
G6S | Tube | Active | Surface Mount | 4.5VDC | DPDT (2 Form C) | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 22.2 mA | Latching, Single Coil | - | Gull Wing | - | - | 3.38 VDC | - | 4 ms | 4 ms | -40°C ~ 85°C | Silver (Ag), Gold (Au) | Telecom | - | - |
|
|
G6SU-2G DC24RELAY TELECOM DPDT 2A 24V |
2,204 |
|
Datasheet |
G6S | Tube | Active | Surface Mount | 24VDC | DPDT (2 Form C) | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 6.3 mA | Latching, Single Coil | - | J Lead | - | - | 18 VDC | - | 4 ms | 4 ms | -40°C ~ 85°C | Silver (Ag), Gold (Au) | Telecom | - | - |
|
|
G6SU-2G DC3RELAY TELECOM DPDT 2A 3V |
3,501 |
|
Datasheet |
G6S | Tube | Active | Surface Mount | 3VDC | DPDT (2 Form C) | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 33.3 mA | Latching, Single Coil | - | J Lead | - | - | 2.25 VDC | - | 4 ms | 4 ms | -40°C ~ 85°C | Silver (Ag), Gold (Au) | Telecom | - | - |
|
|
G6SU-2G DC4.5RELAY TELECOM DPDT 2A 4.5V |
1,892 |
|
Datasheet |
G6S | Tube | Active | Surface Mount | 4.5VDC | DPDT (2 Form C) | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 22.2 mA | Latching, Single Coil | - | J Lead | - | - | 3.38 VDC | - | 4 ms | 4 ms | -40°C ~ 85°C | Silver (Ag), Gold (Au) | Telecom | - | - |
|
|
G6SU-2G DC5RELAY TELECOM DPDT 2A 5V |
1,957 |
|
Datasheet |
G6S | Tube | Active | Surface Mount | 5VDC | DPDT (2 Form C) | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 20 mA | Latching, Single Coil | - | J Lead | - | - | 3.75 VDC | - | 4 ms | 4 ms | -40°C ~ 85°C | Silver (Ag), Gold (Au) | Telecom | - | - |
|
|
G6SU-2G-TR DC4.5RELAY TELECOM DPDT 2A 4.5V |
3,111 |
|
Datasheet |
G6S | Tape & Reel (TR) | Active | Surface Mount | 4.5VDC | DPDT (2 Form C) | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 22.2 mA | Latching, Single Coil | - | J Lead | - | - | 3.38 VDC | - | 4 ms | 4 ms | -40°C ~ 85°C | Silver (Ag), Gold (Au) | Telecom | - | - |
|
HC4ED-H-AC100VRELAY GEN PURPOSE 4PDT 1A 100V |
4,684 |
|
Datasheet |
HCE | Bulk | Obsolete | Socketable | 100VAC | 4PDT (4 Form C) | 1 A | 250VAC - Max | 250VA | 13.2 mA | Non Latching | - | Plug In | - | - | 80 VAC | 30 VAC | 20 ms | 20 ms | -40°C ~ 60°C | Silver Nickel (AgNi), Gold (Au) | General Purpose | - | - |
|
HC4ED-HP-AC100VRELAY GEN PURPOSE 4PDT 1A 100V |
1,086 |
|
Datasheet |
HCE | Bulk | Obsolete | Through Hole | 100VAC | 4PDT (4 Form C) | 1 A | 250VAC - Max | 250VA | 13.2 mA | Non Latching | - | PC Pin | - | - | 80 VAC | 30 VAC | 20 ms | 20 ms | -40°C ~ 60°C | Silver Nickel (AgNi), Gold (Au) | General Purpose | - | - |
|
|
HC4ED-L-AC100VRELAY GEN PURPOSE 4PDT 1A 100V |
2,380 |
|
Datasheet |
HCE | Bulk | Obsolete | Socketable | 100VAC | 4PDT (4 Form C) | 1 A | 250VAC - Max | 250VA | 13.2 mA | Non Latching | Lighted Indicator | Plug In | - | - | 80 VAC | 30 VAC | 20 ms | 20 ms | -40°C ~ 60°C | Silver Nickel (AgNi), Gold (Au) | General Purpose | - | - |
