Safety Relays
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Mounting Type | Coil Voltage | Contact Form | Contact Rating (Current) | Switching Voltage | Features | Termination Style | Must Operate Voltage | Must Release Voltage | Operating Temperature | Contact Material | Operate Time | Release Time |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ASFM0182XRELAY SAFETY DPST NONC 6A/3A 18V |
4,251 |
|
Datasheet |
SF-M | Tape & Reel (TR) | Active | Through Hole | 18VDC | DPST-NO/NC (1 Form A, 1 Form B) | 6 A | 250VAC, 125VDC - Max | Sealed - Flux Protection | PC Pin | 13.5 VDC | 1.8 VDC | 15 ms | 10 ms | -40°C ~ 85°C | Silver Nickel (AgNi) |
|
SF2D-DC48VRELAY SAFETY 4PST 6A 48V |
1,116 |
|
Datasheet |
SF2D | Tray | Active | Through Hole | 48VDC | 4PST-2NO/2NC (2 Form A, 2 Form B) | 6 A | 440VAC, 30VDC - Max | - | PC Pin | 36 VDC | 4.8 VDC | 17 ms | 7 ms | -40°C ~ 70°C | Silver Tin Oxide (AgSnO) |
|
|
SF2D-DC60VRELAY SAFETY 4PST 6A 60V |
3,825 |
|
Datasheet |
SF2D | Tray | Active | Through Hole | 60VDC | 4PST-2NO/2NC (2 Form A, 2 Form B) | 6 A | 440VAC, 30VDC - Max | - | PC Pin | 45 VDC | 6 VDC | 17 ms | 7 ms | -40°C ~ 70°C | Silver Tin Oxide (AgSnO) |
|
56.OA42.1111COA5642 110VDC1NO/1NC CONTACT AGS |
2,780 |
|
Datasheet |
* | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
56.OA42.1111NOA5642 110VDC1NO/1NC CONTACT AGN |
1,423 |
|
Datasheet |
* | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
56.OA42.4811COA5642 48VDC1NO/1NC CONTACTS AGS |
1,778 |
|
Datasheet |
* | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
56.OA42.4811NOA5642 48VDC1NO/1NC CONTACTS AGN |
3,619 |
|
Datasheet |
* | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
56.OA42.6011COA5642 48VDC1NO/1NC CONTACTS AGS |
3,763 |
|
Datasheet |
* | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
56.OA42.6011NOA5642 60VDC1NO/1NC CONTACTS AGN |
2,958 |
|
Datasheet |
* | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
RF1V-2A2B-D24RELAY FORCE GUIDED 2NO2NC DC24 |
2,501 |
|
- |
RF1V | Bulk | Active | Through Hole | 24VDC | 4PST-2NO/2NC (2 Form A, 2 Form B) | 6 A | 250VAC, 30VDC - Max | - | PC Pin | 18 VDC | 2.4 VDC | 20 ms | 20 ms | -40°C ~ 85°C | Silver Tin Oxide (AgSnO), Gold (Au) |
|
|
RF1V-3A1B-D12RELAY FORCE GUIDED 3NO1NC DC12 |
2,633 |
|
- |
RF1V | Bulk | Active | Through Hole | 12VDC | 4PST-3NO/1NC (3 Form A, 1 Form B) | 6 A | 250VAC, 30VDC - Max | - | PC Pin | 9 VDC | 1.2 VDC | 20 ms | 20 ms | -40°C ~ 85°C | Silver Tin Oxide (AgSnO), Gold (Au) |
|
|
RF1V-2A2B-D12RELAY FORCE GUIDED 2NO2NC DC12 |
4,660 |
|
- |
RF1V | Bulk | Active | Through Hole | 12VDC | 4PST-2NO/2NC (2 Form A, 2 Form B) | 6 A | 250VAC, 30VDC - Max | - | PC Pin | 9 VDC | 1.2 VDC | 20 ms | 20 ms | -40°C ~ 85°C | Silver Tin Oxide (AgSnO), Gold (Au) |
|
SFY4-DC21VRELAY SAFETY 6PST 6A 21V |
2,403 |
|
Datasheet |
SF-Y | Tube | Active | Through Hole | 21VDC | 6PST-4NO/2NC (4 Form A, 2 Form B) | 6 A | 250VAC, 30VDC - Max | - | PC Pin | 15.8 VDC | 3.2 VDC | 20 ms | 10 ms | -40°C ~ 70°C | Silver Nickel (AgNi), Gold (Au) |
|
|
SFY4-DC5VRELAY SAFETY 6PST 6A 5V |
1,033 |
|
Datasheet |
SF-Y | Tube | Active | Through Hole | 5VDC | 6PST-4NO/2NC (4 Form A, 2 Form B) | 6 A | 250VAC, 30VDC - Max | - | PC Pin | 3.75 VDC | 0.75 VDC | 20 ms | 10 ms | -40°C ~ 70°C | Silver Nickel (AgNi), Gold (Au) |
|
|
56.OA67S.1200NOA5667S 12V 2CO CONTACTS AGNI10+ |
4,960 |
|
Datasheet |
* | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
RF1V-3A1B-D48RELAY FORCE GUIDED 3NO1NC DC48 |
4,700 |
|
- |
RF1V | Bulk | Active | Through Hole | 48VDC | 4PST-3NO/1NC (3 Form A, 1 Form B) | 6 A | 250VAC, 30VDC - Max | - | PC Pin | 36 VDC | 4.8 VDC | 20 ms | 20 ms | -40°C ~ 85°C | Silver Tin Oxide (AgSnO), Gold (Au) |
|
|
RF1V-2A2B-D48RELAY FORCE GUIDED 2NO2NC DC48 |
3,621 |
|
- |
RF1V | Bulk | Active | Through Hole | 48VDC | 4PST-2NO/2NC (2 Form A, 2 Form B) | 6 A | 250VAC, 30VDC - Max | - | PC Pin | 36 VDC | 4.8 VDC | 20 ms | 20 ms | -40°C ~ 85°C | Silver Tin Oxide (AgSnO), Gold (Au) |
|
|
56.OA42.0611SOA5642 6VDC1NO/1NC CONTACTS AGNI |
3,005 |
|
Datasheet |
* | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
56.OA42.1211SOA5642 12VDC1NO/1NC CONTACTS AGN |
3,163 |
|
Datasheet |
* | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
56.OA42.2111SOA5642 21VDC1NO/1NC CONTACTS AGN |
1,802 |
|
Datasheet |
* | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - |
