Rotary Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Number of Positions | Index Stops | Number of Decks | Number of Poles per Deck | Circuit per Deck | Contact Timing | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Actuator Type | Actuator Length | Angle of Throw | Contact Material | Contact Finish | Mounting Type | Termination Style | Features | Depth Behind Panel |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
50KSPT45-01-2-04NSWITCH ROTARY 4POS 150MA 115V Grayhill Inc. |
1,504 |
|
Datasheet |
50 | Bulk | Active | 4 | Fixed | 1 | 2 | DP4T | Non-Shorting (BBM) | 150mA (AC), 200mA (DC) | 115 V | 28 V | Flatted (6.35mm Dia) | 9.53mm | 45° | - | Gold | Panel Mount, Through Hole | PC Pin | Process Sealed, Shaft and Panel Sealed | 14.63mm |
|
75AP36-01-2-04NSWITCH ROTARY 4POS 200MA 115V Grayhill Inc. |
4,843 |
|
Datasheet |
75 | Bulk | Active | 4 | Fixed | 1 | 2 | DP4T | Non-Shorting (BBM) | 200mA (AC/DC) | 115 V | 30 V | Screwdriver Slot | Flush | 36° | Silver Cadmium Oxide (AgCdO) | Gold | Through Hole | PC Pin | - | 12.42mm |
|
|
75AP36-01-2-05NSWITCH ROTARY 5POS 200MA 115V Grayhill Inc. |
2,703 |
|
Datasheet |
75 | Bulk | Active | 5 | Fixed | 1 | 2 | DP5T | Non-Shorting (BBM) | 200mA (AC/DC) | 115 V | 30 V | Screwdriver Slot | Flush | 36° | Silver Cadmium Oxide (AgCdO) | Gold | Through Hole | PC Pin | - | 12.42mm |
|
|
71B30-02-3-02NSWITCH ROTARY 2POS 250MA 115V Grayhill Inc. |
1,986 |
|
Datasheet |
71 | Bulk | Active | 2 | Fixed | 2 | 3 | 3PDT | Non-Shorting (BBM) | 250mA (AC/DC) | 115 V | 30 V | Flatted (6.35mm Dia) | 9.53mm | 30° | Silver Alloy | - | Panel Mount | Solder Lug | - | 24.87mm |
|
|
75AP36-01-2-02NSWITCH ROTARY 2POS 200MA 115V Grayhill Inc. |
4,822 |
|
Datasheet |
75 | Bulk | Active | 2 | Fixed | 1 | 2 | DPDT | Non-Shorting (BBM) | 200mA (AC/DC) | 115 V | 30 V | Screwdriver Slot | Flush | 36° | Silver Cadmium Oxide (AgCdO) | Gold | Through Hole | PC Pin | - | 12.42mm |
|
|
75CP36-01-2-04NSWITCH ROTARY 4POS 200MA 115V Grayhill Inc. |
1,152 |
|
Datasheet |
75 | Bulk | Active | 4 | Fixed | 1 | 2 | DP4T | Non-Shorting (BBM) | 200mA (AC/DC) | 115 V | 30 V | Knob | 2.92mm | 36° | Silver Cadmium Oxide (AgCdO) | Gold | Through Hole | PC Pin | - | 12.42mm |
|
|
75CP36-01-2-05NSWITCH ROTARY 5POS 200MA 115V Grayhill Inc. |
2,297 |
|
Datasheet |
75 | Bulk | Active | 5 | Fixed | 1 | 2 | DP5T | Non-Shorting (BBM) | 200mA (AC/DC) | 115 V | 30 V | Knob | 2.92mm | 36° | Silver Cadmium Oxide (AgCdO) | Gold | Through Hole | PC Pin | - | 12.42mm |
|
|
51KP30-01-3-03NSWITCH ROTARY 3POS 150MA 115V Grayhill Inc. |
3,029 |
|
Datasheet |
51 | Bulk | Active | 3 | Fixed | 1 | 3 | 3P3T | Non-Shorting (BBM) | 150mA (AC), 200mA (DC) | 115 V | 28 V | Flatted (6.35mm Dia) | 9.53mm | 30° | - | Gold | Panel Mount, Through Hole | PC Pin | - | 13.64mm |
|
|
51KP30-01-3-04NSWITCH ROTARY 4POS 150MA 115V Grayhill Inc. |
3,254 |
|
Datasheet |
51 | Bulk | Active | 4 | Fixed | 1 | 3 | 3P4T | Non-Shorting (BBM) | 150mA (AC), 200mA (DC) | 115 V | 28 V | Flatted (6.35mm Dia) | 9.53mm | 30° | - | Gold | Panel Mount, Through Hole | PC Pin | - | 13.64mm |
|
|
50A45-01-2-03NSWITCH ROTARY 3POS 150MA 115V Grayhill Inc. |
2,184 |
|
Datasheet |
50 | Bulk | Active | 3 | Fixed | 1 | 2 | DP3T | Non-Shorting (BBM) | 150mA (AC), 200mA (DC) | 115 V | 28 V | Flatted (3.17mm Dia) | 9.53mm | 45° | - | Gold | Panel Mount | Solder Lug | - | 18.77mm |
