Rotary Potentiometers, Rheostats
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Resistance (Ohms) | Tolerance | Power (Watts) | Built in Switch | Number of Turns | Features | Taper | Number of Gangs | Adjustment Type | Temperature Coefficient | Rotation | Resistive Material | Termination Style | Actuator Type | Actuator Length | Actuator Diameter | Bushing Thread | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PRV4F0GJS104KAB10POT Vishay Sfernice |
3,442 |
|
Datasheet |
PRV4 | Box | Active | 100k | ±10% | 2W | None | 1.0 | Sealed | Linear | 1 | User Defined | ±300ppm/°C | 300° | Cermet | Solder Lug | Slotted | 0.875" (22.23mm) | 0.250" (6.35mm) | 3/8-32 | Panel Mount |
|
534B1202JLPOT 2K OHM 2W WIREWOUND LINEAR Vishay Sfernice |
4,250 |
|
Datasheet |
534 | Box | Active | 2k | ±5% | 2W | None | 10.0 | - | Linear | 1 | User Defined | 20ppm/°C | 3600° | Wirewound | Solder Lug | Slotted | 0.812" (20.63mm) | 0.250" (6.35mm) | 3/8-32 | Panel Mount |
|
|
P13LFL222MAB10POT 2.2K OHM 1.5W CERMET LINEAR Vishay Sfernice |
1,598 |
|
Datasheet |
P13 | Box | Active | 2.2k | ±20% | 1.5W | None | 1.0 | Sealed | Linear | 1 | User Defined | ±150ppm/°C | 300° | Cermet | Solder Lug | Slotted | 0.984" (25.00mm) | 0.236" (6.00mm) | M10 x 0.75 | Panel Mount |
|
|
PE30L0FL223KLBPOT 22K OHM 1.5W CERMET LOG Vishay Sfernice |
1,965 |
|
Datasheet |
PE30 | Box | Active | 22k | ±10% | 1.5W | None | 1.0 | Sealed | Logarithmic | 1 | User Defined | ±150ppm/°C | 300° | Cermet | Solder Lug | Slotted | 0.984" (25.00mm) | 0.236" (6.00mm) | M10 x 0.75 | Panel Mount |
|
|
249FGJSPXB25501KAPOT 500 OHM 1W CERMET LINEAR Vishay Spectrol |
2,697 |
|
Datasheet |
249 | Box | Active | 500 | ±10% | 1W | None | 1.0 | - | Linear | 1 | Side Adjustment | ±150ppm/°C | 295° | Cermet | PC Pins | Slotted | 0.875" (22.23mm) | 0.250" (6.35mm) | 3/8 | Panel Mount |
|
|
248BBHS0XB25503MAPOT 50K OHM 1/2W PLASTIC LINEAR Vishay Spectrol |
4,615 |
|
Datasheet |
248 | Box | Active | 50k | ±20% | 0.5W, 1/2W | None | 1.0 | - | Linear | 1 | Side Adjustment | ±500ppm/°C | 295° | Conductive Plastic | PC Pins | Slotted | 0.750" (19.05mm) | 0.125" (3.18mm) | 1/4 | Panel Mount |
|
|
P16SNM105MLB15POT 1M OHM 0.12W CERMET LOG Vishay Sfernice |
2,350 |
|
Datasheet |
P16S | Box | Active | 1M | ±20% | 0.12W | None | 1.0 | Sealed | Logarithmic | 1 | User Defined | ±150ppm/°C | 300° | Cermet | Solder Lug | Knob | 0.370" (9.40mm) | 0.630" (16.00mm) | M10 x 0.75 | Panel Mount |
|
|
P16SNM471MLB15POT 470 OHM 1/2W CERMET LOG Vishay Sfernice |
3,858 |
|
Datasheet |
P16S | Box | Active | 470 | ±20% | 0.5W, 1/2W | None | 1.0 | Sealed | Logarithmic | 1 | User Defined | ±150ppm/°C | 300° | Cermet | Solder Lug | Knob | 0.370" (9.40mm) | 0.630" (16.00mm) | M10 x 0.75 | Panel Mount |
|
PE30L0FG102MABPOT 1K OHM 3W CERMET LINEAR Vishay Sfernice |
2,795 |
|
Datasheet |
PE30 | Bulk | Active | 1k | ±20% | 3W | None | 1.0 | Sealed | Linear | 1 | User Defined | ±150ppm/°C | 300° | Cermet | Solder Lug | Slotted | 0.630" (16.00mm) | 0.236" (6.00mm) | M10 x 0.75 | Panel Mount |
|
PE30L0FG472MABPOT 4.7K OHM 3W CERMET LINEAR Vishay Sfernice |
4,813 |
|
Datasheet |
PE30 | Bulk | Active | 4.7k | ±20% | 3W | None | 1.0 | Sealed | Linear | 1 | User Defined | ±150ppm/°C | 300° | Cermet | Solder Lug | Slotted | 0.630" (16.00mm) | 0.236" (6.00mm) | M10 x 0.75 | Panel Mount |
