Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SRR6038-5R0YFIXED IND 5UH 2.9A 24 MOHM SMD Bourns Inc. |
5,070 |
|
Datasheet |
SRR6038 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 5 µH | ±30% | 2.9 A | 2.95A | Shielded | 24mOhm Max | 8.9 @ 7.96MHz | 42.6MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.268" L x 0.268" W (6.80mm x 6.80mm) | 0.157" (4.00mm) |
|
|
SRR6038-120YFIXED IND 12UH 1.7A 53 MOHM SMD Bourns Inc. |
5,032 |
|
Datasheet |
SRR6038 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 12 µH | ±30% | 1.7 A | 1.95A | Shielded | 53mOhm Max | 8.3 @ 2.52MHz | 17.9MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.268" L x 0.268" W (6.80mm x 6.80mm) | 0.157" (4.00mm) |
|
SRR6028-331YFIXED IND 330UH 370MA 1.4OHM SMD Bourns Inc. |
3,955 |
|
Datasheet |
SRR6028 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 330 µH | ±30% | 370 mA | 270mA | Shielded | 1.4Ohm Max | 11 @ 796kHz | 10MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.268" L x 0.268" W (6.80mm x 6.80mm) | 0.118" (3.00mm) |
|
|
SRR6038-6R2YFIXED IND 6.2UH 2.5A 27 MOHM SMD Bourns Inc. |
3,876 |
|
Datasheet |
SRR6038 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 6.2 µH | ±30% | 2.5 A | 2.6A | Shielded | 27mOhm Max | 9 @ 7.96MHz | 42.3MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.268" L x 0.268" W (6.80mm x 6.80mm) | 0.157" (4.00mm) |
|
|
SRR6028-100YFIXED IND 10UH 2A 65 MOHM SMD Bourns Inc. |
2,582 |
|
Datasheet |
SRR6028 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 10 µH | ±30% | 2 A | 1.7A | Shielded | 65mOhm Max | 11 @ 2.52MHz | 25MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.268" L x 0.268" W (6.80mm x 6.80mm) | 0.118" (3.00mm) |
|
SRR7032-220MFIXED IND 22UH 960MA 135MOHM SMD Bourns Inc. |
2,345 |
|
Datasheet |
SRR7032 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 22 µH | ±20% | 960 mA | 1.05A | Shielded | 135mOhm Max | 20 @ 2.52MHz | 29MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.276" L x 0.276" W (7.00mm x 7.00mm) | 0.134" (3.40mm) |
|
|
SRR7032-221MFIXED IND 220UH 300MA 1.3OHM SMD Bourns Inc. |
1,698 |
|
Datasheet |
SRR7032 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 220 µH | ±20% | 300 mA | 320mA | Shielded | 1.3Ohm Max | 47 @ 796kHz | 7.5MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.276" L x 0.276" W (7.00mm x 7.00mm) | 0.134" (3.40mm) |
|
|
SRR7032-101MFIXED IND 100UH 450MA 540MOHM SM Bourns Inc. |
1,260 |
|
Datasheet |
SRR7032 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 100 µH | ±20% | 450 mA | 500mA | Shielded | 540mOhm Max | 28 @ 796kHz | 12MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.276" L x 0.276" W (7.00mm x 7.00mm) | 0.134" (3.40mm) |
|
SRR4028-101YFIXED IND 100UH 510MA 600MOHM SM Bourns Inc. |
77,149 |
|
Datasheet |
SRR4028 | 1919 (4848 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 100 µH | ±30% | 510 mA | 300mA | Shielded | 600mOhm Max | 8.78 @ 796kHz | 9MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.118" (3.00mm) |
|
|
SRR4028-221YFIXED IND 220UH 340MA 1.25OHM SM Bourns Inc. |
59,877 |
|
Datasheet |
SRR4028 | 1919 (4848 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 220 µH | ±30% | 340 mA | 200mA | Shielded | 1.25Ohm Max | 11.3 @ 796kHz | 5MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.118" (3.00mm) |
