Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
FIT80-4-BFIXED IND 65.04UH 6.8A 32.8 MOHM Triad Magnetics |
1,306 |
|
Datasheet |
FIT | Radial, Vertical (Open) | Bulk | Active | Toroidal | Iron Powder | 65.04 µH | - | 6.8 A | - | Unshielded | 32.8mOhm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Through Hole | - | 0.975" L x 0.625" W (24.76mm x 15.88mm) | 1.100" (27.94mm) |
|
|
FIT80-5-BFIXED IND 47.7UH 8.1A 22.5 MOHM Triad Magnetics |
1,324 |
|
Datasheet |
FIT | Radial, Vertical (Open) | Bulk | Active | Toroidal | Iron Powder | 47.7 µH | - | 8.1 A | - | Unshielded | 22.5mOhm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Through Hole | - | 0.975" L x 0.625" W (24.76mm x 15.88mm) | 1.100" (27.94mm) |
|
|
FIT80-6-BFIXED IND 38.07UH 9.7A 17MOHM TH Triad Magnetics |
1,705 |
|
Datasheet |
FIT | Radial, Vertical (Open) | Bulk | Active | Toroidal | Iron Powder | 38.07 µH | - | 9.7 A | - | Unshielded | 17mOhm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Through Hole | - | 0.975" L x 0.625" W (24.76mm x 15.88mm) | 1.100" (27.94mm) |
|
FIT106-2FIXED IND 197UH 4.8A 106 MOHM TH Triad Magnetics |
2,903 |
|
Datasheet |
FIT | Radial, Vertical (Open) | Bulk | Active | Toroidal | Iron Powder | 197 µH | - | 4.8 A | - | Unshielded | 106mOhm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Through Hole | - | 1.300" L x 0.725" W (33.02mm x 18.42mm) | 1.400" (35.56mm) |
|
|
FIT106-5FIXED IND 93UH 8.1A 39.1 MOHM TH Triad Magnetics |
3,064 |
|
Datasheet |
FIT | Radial, Vertical (Open) | Bulk | Active | Toroidal | Iron Powder | 93 µH | - | 8.1 A | - | Unshielded | 39.1mOhm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Through Hole | - | 1.300" L x 0.725" W (33.02mm x 18.42mm) | 1.400" (35.56mm) |
|
|
FIT106-1-BFIXED IND 253UH 4A 139 MOHM TH Triad Magnetics |
3,514 |
|
Datasheet |
FIT | Radial, Vertical (Open) | Bulk | Active | Toroidal | Iron Powder | 253 µH | - | 4 A | - | Unshielded | 139mOhm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Through Hole | - | 1.300" L x 0.725" W (33.02mm x 18.42mm) | 1.400" (35.56mm) |
|
|
FIT106-2-BFIXED IND 197UH 4.8A 106 MOHM TH Triad Magnetics |
3,378 |
|
Datasheet |
FIT | Radial, Vertical (Open) | Bulk | Active | Toroidal | Iron Powder | 197 µH | - | 4.8 A | - | Unshielded | 106mOhm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Through Hole | - | 1.300" L x 0.725" W (33.02mm x 18.42mm) | 1.400" (35.56mm) |
|
|
FIT106-5-BFIXED IND 93UH 8.1A 39.1 MOHM TH Triad Magnetics |
1,347 |
|
Datasheet |
FIT | Radial, Vertical (Open) | Bulk | Active | Toroidal | Iron Powder | 93 µH | - | 8.1 A | - | Unshielded | 39.1mOhm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Through Hole | - | 1.300" L x 0.725" W (33.02mm x 18.42mm) | 1.400" (35.56mm) |
|
|
FIT106-6-BFIXED IND 70.05UH 9.7A 24MOHM TH Triad Magnetics |
3,604 |
|
Datasheet |
FIT | Radial, Vertical (Open) | Bulk | Active | Toroidal | Iron Powder | 70.05 µH | - | 9.7 A | - | Unshielded | 24mOhm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Through Hole | - | 1.300" L x 0.725" W (33.02mm x 18.42mm) | 1.400" (35.56mm) |
|
FIE220-1FIXED IND 11.7UH 120A 1 MOHM TH Triad Magnetics |
1,018 |
|
Datasheet |
FIE220 | 24-DIP Module | Bulk | Obsolete | Drum Core, Wirewound | Ferrite | 11.7 µH | ±10% | 120 A | - | Unshielded | 1mOhm | - | - | - | - | 10 kHz | - | Through Hole | - | 2.350" L x 2.050" W (59.69mm x 52.07mm) | 2.050" (52.07mm) |
