Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
-1,80mm.jpg)
|
LB2016T3R3MFIXED IND 3.3UH 285MA 200MOHM SM Taiyo Yuden |
3,703 |
|
Datasheet |
LB | 0806 (2016 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 3.3 µH | ±20% | 285 mA | - | Unshielded | 200mOhm | - | 55MHz | - | -25°C ~ 105°C | 7.96 MHz | - | Surface Mount | 0806 (2016 Metric) | 0.079" L x 0.063" W (2.00mm x 1.60mm) | 0.071" (1.80mm) |
|
|
LB2016T470MFIXED IND 47UH 70MA 2.4 OHM SMD Taiyo Yuden |
2,949 |
|
Datasheet |
LB | 0806 (2016 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 47 µH | ±20% | 70 mA | - | Unshielded | 2.4Ohm | - | 11MHz | - | -25°C ~ 105°C | 2.52 MHz | - | Surface Mount | 0806 (2016 Metric) | 0.079" L x 0.063" W (2.00mm x 1.60mm) | 0.071" (1.80mm) |
-2,00mm.jpg)
|
LBC2518T150KFIXED IND 15UH 285MA 650MOHM SMD Taiyo Yuden |
2,636 |
|
Datasheet |
LB, C Type | 1007 (2518 Metric) | Tape & Reel (TR) | Active | Wirewound | - | 15 µH | ±10% | 285 mA | - | Unshielded | 650mOhm | - | 23MHz | - | -25°C ~ 105°C | 2.52 MHz | - | Surface Mount | 1007 (2518 Metric) | 0.098" L x 0.071" W (2.50mm x 1.80mm) | 0.079" (2.00mm) |
|
|
LBC2518T151MFIXED IND 150UH 95MA 6.1 OHM SMD Taiyo Yuden |
3,334 |
|
Datasheet |
LB, C Type | 1007 (2518 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 150 µH | ±20% | 95 mA | - | Unshielded | 6.1Ohm | - | 7MHz | - | -25°C ~ 105°C | 796 kHz | - | Surface Mount | 1007 (2518 Metric) | 0.098" L x 0.071" W (2.50mm x 1.80mm) | 0.079" (2.00mm) |
|
|
LBC2518T330KFIXED IND 33UH 185MA 1.5 OHM SMD Taiyo Yuden |
3,761 |
|
Datasheet |
LB, C Type | 1007 (2518 Metric) | Tape & Reel (TR) | Active | Wirewound | - | 33 µH | ±10% | 185 mA | - | Unshielded | 1.5Ohm | - | 15MHz | - | -25°C ~ 105°C | 2.52 MHz | - | Surface Mount | 1007 (2518 Metric) | 0.098" L x 0.071" W (2.50mm x 1.80mm) | 0.079" (2.00mm) |
|
LBC2518T330MFIXED IND 33UH 185MA 1.5 OHM SMD Taiyo Yuden |
3,804 |
|
Datasheet |
LB, C Type | 1007 (2518 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 33 µH | ±20% | 185 mA | - | Unshielded | 1.5Ohm | - | 15MHz | - | -40°C ~ 105°C | 2.52 MHz | - | Surface Mount | 1007 (2518 Metric) | 0.098" L x 0.071" W (2.50mm x 1.80mm) | 0.079" (2.00mm) |
-0,95mm.jpg)
|
LK16081R0M-TFIXED IND 1UH 40MA 600 MOHM SMD Taiyo Yuden |
2,737 |
|
Datasheet |
LK | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | 1 µH | ±20% | 40 mA | - | Shielded | 600mOhm Max | 35 @ 100MHz | 70MHz | - | -40°C ~ 85°C | 10 MHz | - | Surface Mount | 0603 (1608 Metric) | 0.063" L x 0.031" W (1.60mm x 0.80mm) | 0.037" (0.95mm) |
-1,45mm.jpg)
|
CKS21251R0M-TFIXED IND 1UH 280MA 120 MOHM SMD Taiyo Yuden |
1,274 |
|
Datasheet |
CK, S Type | 0805 (2012 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | Ferrite | 1 µH | ±20% | 280 mA | - | Unshielded | 120mOhm Max | - | 75MHz | - | -40°C ~ 85°C | 10 MHz | - | Surface Mount | 0805 (2012 Metric) | 0.079" L x 0.049" W (2.00mm x 1.25mm) | 0.057" (1.45mm) |
|
NRS6010T220MMGFFIXED IND 22UH 700MA 580MOHM SMD Taiyo Yuden |
2,456 |
|
- |
NR, S Type | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 22 µH | ±20% | 700 mA | 650mA | Shielded | 580mOhm Max | - | 12MHz | - | -25°C ~ 120°C | 100 kHz | - | Surface Mount | - | 0.236" L x 0.236" W (6.00mm x 6.00mm) | 0.039" (1.00mm) |
|
LLXND6060WKL4R7NMGFIXED IND 4.7UH 2.15A 69.6 MOHM Taiyo Yuden |
3,500 |
|
- |
LLXN | 2424 (6060 Metric) | Tape & Reel (TR) | Active | Wirewound | Ferrite | 4.7 µH | ±30% | 2.15 A | 2.4A | Shielded | 58mOhm | - | 43MHz | - | -25°C ~ 125°C | 100 kHz | - | Surface Mount | 2424 | 0.236" L x 0.236" W (6.00mm x 6.00mm) | 0.079" (2.00mm) |
