CPLDs (Complex Programmable Logic Devices)
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Programmable | Programmable Type | Delay Time tpd(1) Max | Voltage Supply - Internal | Number of Logic Elements/Blocks | Number of Macrocells | Number of Gates | Number of I/O | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
.jpg)
|
ATF750LVC-15JUIC CPLD 10MC 15NS 28PLCC Microchip Technology |
128 |
|
Datasheet |
ATF750LVC | 28-LCC (J-Lead) | Tube | Active | Verified | EE PLD | 15 ns | 3V ~ 5.5V | - | 10 | - | 10 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 28-PLCC (11.51x11.51) |
|
ATF1504ASL-25AU44IC CPLD 64MC 25NS 44TQFP Microchip Technology |
328 |
|
Datasheet |
ATF15xx | 44-TQFP | Tray | Active | Verified | In System Programmable (min 10K program/erase cycles) | 25 ns | 4.5V ~ 5.5V | - | 64 | - | 32 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 44-TQFP (10x10) |
|
|
ATF750C-10JUIC CPLD 10MC 10NS 28PLCC Microchip Technology |
146 |
|
Datasheet |
ATF750C(L) | 28-LCC (J-Lead) | Tube | Active | Verified | EE PLD | 10 ns | 4.5V ~ 5.5V | - | 10 | - | 10 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 28-PLCC (11.51x11.51) |
|
ATF1508ASV-15AU100-TIC CPLD 128MC 15NS 100TQFP Microchip Technology |
346 |
|
Datasheet |
ATF15xx | 100-TQFP | Tape & Reel (TR) | Active | Not Verified | In System Programmable (min 10K program/erase cycles) | 15 ns | 3V ~ 3.6V | - | 128 | - | 80 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 100-TQFP (14x14) |
|
ATF750C-10PUIC CPLD 10MC 10NS 24DIP Microchip Technology |
194 |
|
Datasheet |
ATF750C(L) | 24-DIP (0.300", 7.62mm) | Tube | Active | Verified | EE PLD | 10 ns | 4.5V ~ 5.5V | - | 10 | - | 10 | -40°C ~ 85°C (TA) | - | - | Through Hole | 24-PDIP |
|
ATF2500C-20KMIC CPLD 24MC 20NS 44JLCC Microchip Technology |
2,866 |
|
Datasheet |
ATF2500C(L) | 44-CLCC (J-Lead) | Tube | Active | Verified | In System Programmable | 20 ns | 4.5V ~ 5.5V | - | 24 | - | 24 | -55°C ~ 125°C (TC) | - | - | Surface Mount | 44-JLCC (16.63x16.63) |
|
|
ATF1500AL-20AUIC CPLD 32MC 20NS 44TQFP Microchip Technology |
437 |
|
Datasheet |
ATF15xx | 44-TQFP | Tray | Active | Verified | In System Programmable (min 100 program/erase cycles) | 20 ns | 4.5V ~ 5.5V | - | 32 | - | 32 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 44-TQFP (10x10) |
|
|
ATF750C-7JXIC CPLD 10MC 7.5NS 28PLCC Microchip Technology |
112 |
|
Datasheet |
ATF750C(L) | 28-LCC (J-Lead) | Tube | Active | Verified | EE PLD | 7.5 ns | 4.75V ~ 5.25V | - | 10 | - | 10 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 28-PLCC (11.51x11.51) |
|
|
ATF1504AS-7AX100IC CPLD 64MC 7.5NS 100TQFP Microchip Technology |
178 |
|
Datasheet |
ATF15xx | 100-TQFP | Tray | Active | Not Verified | In System Programmable (min 10K program/erase cycles) | 7.5 ns | 4.75V ~ 5.25V | - | 64 | - | 64 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 100-TQFP (14x14) |
|
ATF1504ASV-15JU44IC CPLD 64MC 15NS 44PLCC Microchip Technology |
243 |
|
Datasheet |
ATF15xx | 44-LCC (J-Lead) | Tube | Active | Verified | In System Programmable (min 10K program/erase cycles) | 15 ns | 3V ~ 3.6V | - | 64 | - | 32 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 44-PLCC (16.6x16.6) |
