CPLDs (Complex Programmable Logic Devices)
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Programmable | Programmable Type | Delay Time tpd(1) Max | Voltage Supply - Internal | Number of Logic Elements/Blocks | Number of Macrocells | Number of Gates | Number of I/O | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
EPS448JC-25UV PLD, CMOS, CQCC28 Altera |
2,548 |
|
Datasheet |
- | 28-CLCC Window (J-Lead) | Bulk | Active | Not Verified | EPLD | - | 4.75V ~ 5.25V | - | - | - | - | 0°C ~ 70°C (TA) | - | - | Surface Mount | 28-JLCC |
|
|
EPS448JC-25AUV PLD CQCC28 Altera |
4,913 |
|
Datasheet |
- | 28-CLCC Window (J-Lead) | Bulk | Active | Not Verified | EPLD | - | 4.75V ~ 5.25V | - | - | - | - | 0°C ~ 70°C (TA) | - | - | Surface Mount | 28-JLCC |
|
EPX740LC44-10ZIC CPLD 40MC 10NS 44PLCC Altera |
1,782 |
|
Datasheet |
- | 44-LCC (J-Lead) | Bulk | Active | Not Verified | EPLD | 10 ns | 4.75V ~ 5.25V | 16 | 40 | 800 | - | 0°C ~ 70°C (TA) | - | - | Surface Mount | 44-PLCC (16.59x16.59) |
|
EPM2210GF324C3IC CPLD 1700MC 7NS 324FBGA Altera |
2,300 |
|
Datasheet |
MAX® II | 324-BGA | Bulk | Active | Not Verified | In System Programmable | 7 ns | 1.71V ~ 1.89V | 2210 | 1700 | - | 272 | 0°C ~ 85°C (TJ) | - | - | Surface Mount | 324-FBGA (19x19) |
|
EPM7512BTC144-10IC CPLD 512MC 10NS 144TQFP Altera |
4,606 |
|
Datasheet |
MAX® 7000B | 144-LQFP | Bulk | Active | Not Verified | In System Programmable | 10 ns | 2.375V ~ 2.625V | 32 | 512 | 10000 | 120 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 144-TQFP (20x20) |
|
EPM7064LI84-10IC CPLD 64MC 10NS 84PLCC Altera |
1,689 |
|
Datasheet |
MAX® 7000 | 84-LCC (J-Lead) | Bulk | Active | Not Verified | EE PLD | 10 ns | 4.5V ~ 5.5V | 4 | 64 | 1250 | 68 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 84-PLCC (29.31x29.31) |
|
EPM7064BTC100-7IC CPLD 64MC 7.5NS 100TQFP Altera |
2,130 |
|
Datasheet |
MAX® 7000B | 100-TQFP | Bulk | Active | Not Verified | EE PLD | 7.5 ns | 2.375V ~ 2.625V | 4 | 64 | 1250 | 68 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 100-TQFP (14x14) |
|
EPM3032ATI44-10EE PLD, 10NS, 32-CELL, CMOS, PQF Altera |
2,858 |
|
- |
MAX® 3000A | 44-TQFP | Tray | Active | Not Verified | In System Programmable | 10 ns | 3V ~ 3.6V | 2 | 32 | 600 | 34 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 44-TQFP (10x10) |
|
|
EPM7032AELC44-4IC CPLD 32MC 4.5NS 44PLCC Altera |
2,730 |
|
Datasheet |
MAX® 7000A | 44-LCC (J-Lead) | Bulk | Active | Not Verified | In System Programmable | 4.5 ns | 3V ~ 3.6V | 2 | 32 | 600 | 36 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 44-PLCC (16.59x16.59) |
|
EPM3512AQI208-10NCPLD - COMPLEX PROGRAMMABLE LOGI Altera |
2,448 |
|
Datasheet |
MAX® 3000A | 208-BFQFP | Tray | Active | Not Verified | In System Programmable | 10 ns | 3V ~ 3.6V | 32 | 512 | 10000 | 172 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 208-PQFP (28x28) |
